제품 상세정보
원래 장소: 중국
브랜드 이름: Brans
모델 번호: WLSM-132
문서: WLSM-132 High Accuracy Load...NS.pdf
지불과 운송 용어
최소 주문 수량: 1 PC
배달 시간: 일주일
지불 조건: 티/티
공급 능력: 800 PC / 달
용량: |
30g/50g/100g/300g /500g/1kg/2kg |
종합 오차: |
≤0.005%FS |
비선형 성: |
≤0.005%FS |
반복성: |
≤0.005%FS |
정격 출력: |
1.0mV/V |
제로 밸런스: |
±0.05mV/V |
절연저항: |
5000mΩ/100VDC |
재료: |
알루미늄 합금 |
안전한 과부하: |
150%F.S. |
보호 등급: |
IP66 (사용자 정의 가능) |
작동 온도.: |
-30~80°C |
케이블 크기: |
Ф3.2x4000mm(맞춤형) |
용량: |
30g/50g/100g/300g /500g/1kg/2kg |
종합 오차: |
≤0.005%FS |
비선형 성: |
≤0.005%FS |
반복성: |
≤0.005%FS |
정격 출력: |
1.0mV/V |
제로 밸런스: |
±0.05mV/V |
절연저항: |
5000mΩ/100VDC |
재료: |
알루미늄 합금 |
안전한 과부하: |
150%F.S. |
보호 등급: |
IP66 (사용자 정의 가능) |
작동 온도.: |
-30~80°C |
케이블 크기: |
Ф3.2x4000mm(맞춤형) |
Features & Applications
Specifications
| Capacity | 30g/50g/100g/300g /500g/1kg/2kg |
| Combined Error | ≤0.005%F.S. |
| Non-linearity | ≤0.005%F.S. |
| Repeatability | ≤0.005%F.S. |
| Rated Output | 1.0mV/V |
| Zero Balance | 0.05mV/V |
| Insulation Resistance | ≧5000MΩ/100VDC |
| Recommended Excitation | 2~12VDC |
| Material | Aluminum Alloy |
| Safe Overload | 150%F.S. |
| Protection Class | IP66(Customizable) |
| Operation Temp. | -30~80°C |
| Cable Size | Ф3.2x4000mm(Customizable) |
| Nominal Displacement | <0.05mm |
Dimensions(mm)
Load direction
Wiring code
Shipping & Packaging
To ensure safe arrival at your location, the load cell will be carefully packaged and shipped. The packing process is as follows:
1. The load cell will be placed in a sturdy cardboard box to protect it from external damage during shipping.
2. The box will be filled with foam padding to provide additional cushioning and prevent the load cell from moving during shipping.
3. The load cell will be sealed in a plastic bag to protect it from moisture and other environmental factors.
4. Additional layers of bubble wrap will be provided for additional protection.
5. The carton is securely taped to prevent tampering.
6. A shipping label with your address and product information is attached to the box.
7. The package is shipped using a reliable and trusted freight carrier.
Once the package is shipped, you will receive a tracking number to monitor the status of your delivery. Please ensure that someone is available at the delivery address to receive the package to avoid any delays or problems.
