제품 상세정보
원래 장소: 중국
브랜드 이름: Brans
모델 번호: DQ-309H-01
지불과 운송 용어
최소 주문 수량: 1개
포장 세부 사항: Standard exporter carton packing including of instructions. 지침이 포함된 표준 수출업체 상자 포장.
배달 시간: 5-7 근무일
지불 조건: L/C, T/T, 웨스턴 유니온, 페이팔
보증기간: |
12개월 |
정확성: |
연결된 센서에 따라 다릅니다. 송신기 디스플레이 해상도 최대 200,000 |
디스플레이 유형: |
0.96인치 OLED, 중국어/영어 선택 가능 |
표시 자리수: |
최대. 표시 범위 200,000(6자리) |
하우징 재료: |
ABS 난연성 소재 |
치수(l*w*h): |
90mm × 84mm × 42mm |
보증기간: |
12개월 |
정확성: |
연결된 센서에 따라 다릅니다. 송신기 디스플레이 해상도 최대 200,000 |
디스플레이 유형: |
0.96인치 OLED, 중국어/영어 선택 가능 |
표시 자리수: |
최대. 표시 범위 200,000(6자리) |
하우징 재료: |
ABS 난연성 소재 |
치수(l*w*h): |
90mm × 84mm × 42mm |
DQ-309H Digital Transmitter – Multi-Channel Industrial Weighing & Force Measurement
Product Description:
The DQ-309H is a DIN35mm rail-mountable digital transmitter designed for multi-channel industrial force measurement and weighing applications. It supports up to 6 independent ADC channels and is compatible with analog resistive strain gauge sensors (sensitivity output: -3mV/V to 3mV/V). Equipped with high-speed Ethernet data transmission, MODBUS-RTU and MODBUS-TCP protocols, and simultaneous RS232/RS485 communication, the DQ-309H delivers reliable, interference-resistant performance in demanding industrial environments.
Brans are always devoted to deliver satisfied and favourable services to each our clients to meet their specific needs. We deeply understand that each apllication is different and requires a customized response.To make sure
providing the best solution, the transmitter can be adapted to meet customer requirements.
Features:
DIN35mm standard rail mounting with fixing clip
0.96-inch OLED display (Chinese/English selectable)
High-speed Ethernet data transmission, strong anti-interference
Supports MODBUS-RTU and MODBUS-TCP output
Simultaneous use of RS232 and RS485
Supports 4–6 x 350Ω load cells
Maximum display range: 200,000
Power supply: 24VDC ±1%, power ≤10W
4 membrane keys for operation
Operating temperature: -10°C to 40°C; humidity: 10%–95% non-condensing
Dimensions: 90mm×84mm×42mm; ABS flame-retardant housing; IP20 protection
Applications:
Ideal for multi-channel industrial force measurement and weighing applications requiring up to 6 independent ADC channels, resistive strain gauge sensors, and high-speed Ethernet data transmission with good noise immunity.
Specifications:
| Signal Type | Analog resistive strain gauge sensor (sensitivity output: -3mV/V ~ 3mV/V) |
| Input Load (Number of Sensors) | 4–6 pcs of 350Ω sensors |
| Communication Interface | Ethernet, RS232, RS485 |
| Communication Protocol | MODBUS-RTU, MODBUS-TCP |
| Display | 0.96-inch OLED, Chinese/English selectable |
| Display Resolution | Maximum display range: 200,000 |
| Power Supply | 24VDC ±1%, power consumption ≤10W |
| Function Keys | 4 membrane keys |
| Operating Environment | Temperature: -10°C ~ 40°C (-14°F ~ 104°F); Relative humidity: 10% ~ 95%, non-condensing |
| Dimensions (L × W × H) | 90mm × 84mm × 42mm |
| Housing Material | ABS flame-retardant housing |
| Number of Channels | Supports up to 6 independent ADC channels |
| Protection Class | IP20 |
Packaging and Shipping
To ensure safe arrival at your location, the product will be carefully packaged and shipped. The packing process is as follows:
1. The product will be placed in a sturdy cardboard box to protect it from external damage during shipping.
2. The box will be filled with foam padding to provide additional cushioning and prevent the product from moving during shipping.
3. The product will be sealed in a plastic bag to protect it from moisture and other environmental factors.
4. Additional layers of bubble wrap will be provided for additional protection.
5. The carton is securely taped to prevent tampering.
6. A shipping label with your address and product information is attached to the box.
7. The package is shipped using a reliable and trusted freight carrier.
Once the package is shipped, you will receive a tracking number to monitor the status of your delivery. Please ensure that someone is available at the delivery address to receive the package to avoid any delays or problems.
